FT-36PGM545 Planetary Geared Brushless Dc Motor
Product Advantages
| SPECIFICATIONS | |||||||||
| The specifications aaccept customization | |||||||||
| Model number | Rated volt. | No load | Load | Stall | |||||
| Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| rpm | mA(max) | rpm | mA(max) | Kgf.cm | W | mA(min) | Kgf.cm | ||
| FT-36PGM5550126000-5.2K | 12V | 1153 | 650 | 960 | 3000 | 1.2 | 11.8 | 10620 | 6.3 |
| FT-36PGM5550128000-14K | 12V | 571 | 900 | 465 | 3500 | 4 | 19.1 | 11550 | 19 |
| FT-36PGM5550126000-27K | 12V | 223 | 400 | 175 | 1600 | 4.2 | 7.5 | 5350 | 20 |
| FT-36PGM5550126000-51K | 12V | 117 | 680 | 85 | 2680 | 13 | 11.3 | 8350 | 60 |
| FT-36PGM5550126000-71K | 12V | 84 | 500 | 70 | 2400 | 14 | 10.1 | 8380 | 71 |
| FT-36PGM5550126000-99.5K | 12V | 60 | 450 | 48 | 2000 | 16 | 7.9 | 6300 | 78 |
| FT-36PGM5550124500-264K | 12V | 17 | 400 | 12 | 1500 | 28 | 3.4 | 2800 | 104 |
| FT-36PGM5550126000-721K | 12V | 8 | 400 | 6 | 3200 | 160 | 9.9 | 9000 | 630 |
| FT-36PGM5550246000-3.7K | 24V | 1621 | 500 | 1216 | 2000 | 1.5 | 18.7 | 8000 | 7.5 |
| FT-36PGM5550246000-5.2K | 24V | 1153 | 400 | 1016 | 1600 | 1.25 | 13 | 5380 | 8 |
| FT-36PGM5550124500-27K | 24V | 167 | 550 | 147 | 2000 | 6 | 9.1 | 6500 | 30 |
| FT-36PGM5550244500-71K | 24V | 63 | 220 | 48 | 1100 | 10 | 4.9 | 3700 | 50 |
| FT-36PGM5550243000-100K | 24V | 30 | 150 | 22 | 550 | 12 | 2.7 | 1180 | 55 |
| FT-36PGM5550246000-189K | 24V | 31 | 360 | 26 | 1800 | 41 | 10.9 | 4730 | 204 |
| FT-36PGM5550244500-264K | 24V | 17 | 220 | 14 | 1000 | 43 | 6.2 | 2700 | 221 |
| FT-36PGM5550244500-369K | 24V | 12 | 250 | 9 | 850 | 70 | 6.5 | 2500 | 280 |
| FT-36PGM5550246000-1367K | 24V | 4.3 | 450 | 3.2 | 2000 | 250 | 8.2 | 6500 | 1200 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in | |||||||||
The dc planetary gear motor impact crosses into the healthcare sector as well. In massage health care, beauty and fitness equipment, and medical equipment, this motor provides consistent power and reliability. Massagers deliver soothing and therapeutic massage sessions, beauty equipment aids in enhancing one's appearance, and medical equipment operates accurately, improving the well-being of patients.
1、High torque
2、Compact structure
3、High precision
4、High efficiency
5、Low noise
6、Reliability
7、Diversified choices
Product Video
Application
DC Gear Motor Widely Used In Smart home appliances, Smart pet products ,Robots, Electronic locks, Public bicycle locks, Electric daily necessities, ATM machine , Electric glue guns, 3D printing pens, Office equipment, Massage health care, Beauty and fitness equipment, Medical equipment, Toys, Curling iron, Automotive automatic facilities.
Company Profile
About This Item
Our motors are designed to address the limitations and challenges of traditional DC motors, delivering superior performance and durability.
Due to their size and the use of metal brush commutators, the speed range of conventional DC motors is typically limited to 2 to 2000 rpm. However, faster speeds shorten motor life, leading to frequent replacements and increased maintenance costs. With our planetary gearmotors, these limitations are a thing of the past.
One of the outstanding features of our motors is the use of a low-noise DC motor with an internal ring varistor. This clever addition effectively reduces electromagnetic interference to the environment, ensuring quiet, efficient operation. Whether you need a motor for a residential or commercial application, our planetary gear motors provide an unparalleled user experience.
